Engineered Industrial Shelving & Racking Portfolios
Discover high-density longspan shelving, multi-tier racking, and rack-supported modular mezzanines manufactured under ISO 9001 and CE compliance for industrial distribution setups in Sri Lanka.
Adjustable Industrial Warehouse Stacking Racks Multi Tier Storage Rack Units
Send an Inquiry
Longspan Shelving Engineering for Sri Lanka's Modern Warehouses
The rapid expansion of Sri Lanka's domestic supply chain network—anchored by the logistics hubs of the Western Province, industrial export processing zones (EPZs) in Katunayake, Biyagama, and Mirigama, and the burgeoning transit traffic through the Port of Colombo—has driven an urgent requirement for high-density, vertical, and corrosion-resistant storage systems. Warehousing enterprises, third-party logistics (3PL) providers, and garment manufacturing giants across Colombo, Gampaha, and Kandy increasingly face high commercial real estate overheads. Maximizing volumetric storage density through longspan shelving systems and rack-supported multi-tier platforms has transitioned from an operational upgrade to a financial necessity.
Unlike light-duty retail racks or monolithic pallet-only systems, industrial longspan shelving bridges the critical gap between manual picking efficiency and heavy-duty load distribution. Engineered for medium to heavy hand-loaded goods, bin storage, carton buffering, and apparel handling, our longspan systems offer uncompromised vertical adjustability with clear spans ranging from 1,200 mm to 2,700 mm and shelf capacities from 300 kg to over 1,000 kg per level.
Apparel & Garment Logistics
Tailored for Katunayake & Biyagama export clusters. Configured with wide-span drop-in timber or steel panels, hanger bars, and wire decking to streamline carton sorting, bolt fabric staging, and dynamic SKU order fulfillment.
FMCG & Fast-Track E-Commerce
Ideal for high-throughput fulfillment centers in Kelaniya and Peliyagoda. Allows ultra-dense pick-face creation, integration with gravity roller accessories, and uninterrupted picking pathways for high inventory turnover.
Pharma & Cold-Chain Transition
Complies with strict GMP distribution standards. Powder-coated with non-toxic, antibacterial electrostatic finishes that withstand sanitization washdowns and high-humidity ambient buffering without flaking.
Engineering for Tropical Humidity & Island Logistics Realities
Sri Lanka's coastal geographic profile results in persistent relative humidity levels frequently exceeding 75% to 85% in areas surrounding Colombo Harbor and coastal processing corridors. In untreated warehouse environments, atmospheric salt particles and condensation drastically accelerate electrolytic corrosion on conventional cold-rolled steel edges. When procuring imported shelving from China, evaluating corrosion mitigation is a critical engineering requirement.
Our longspan frames and step beams undergo an industrial 10-stage automated surface pretreatment process: degreasing, multi-stage acid pickling, zinc phosphating, and deionized water rinsing, followed by thermosetting electrostatic polyester epoxy powder coating cured at 180°C–200°C. This creates an impermeable cross-linked coating barrier (60–90 microns thick) resistant to chemical attack, chalking, and micro-cracking. For deep cold-chain zones or semi-open port sheds, hot-dip galvanized uprights and zinc wire mesh decks provide corrosion resistance that meets and exceeds international ISO 9227 salt-spray test benchmarks.
| Structural Parameter | Standard Longspan Tier | Heavy-Duty Longspan / Mezzanine Sub-tier | Verification Standard |
|---|---|---|---|
| Steel Grade | Q235B High-Tensile Structural Steel | Q355B Cold-Formed Certified Coil | GB/T 700 / ASTM A36 Equiv. |
| Load Capacity Per Level | 300 kg – 600 kg (Uniformly Distributed) | 600 kg – 1,200 kg (Uniformly Distributed) | EN 15512:2020 Protocol |
| Upright Frame Depth | 500 / 600 / 800 / 1000 mm | 800 / 1000 / 1100 / 1200 mm | Customized Layout Drafting |
| Beam Pitch Adjustability | 50 mm Pitch Punching Interval | 50 mm / 75 mm Teardrop/Butterfly Pitch | Modular Tool-less Reconfiguration |
| Surface Treatment | 10-Stage Phosphating + Powder Coat (70µm) | Hot-Dip Galvanized or Epoxy Powder Coat | ISO 9227 Salt Spray Verification |
| Decking Surface Options | Galvanized Steel Shelves / High-Density MDF | Heavy Ribbed Steel Plates / Welded Wire Mesh | Fire-Sprinkler Permeable Codes |
Why Sri Lankan Logistics Leaders Partner Directly With Our Factory
Eliminating intermediaries to deliver high-precision engineering, factory-direct pricing, guaranteed steel quality, and sea-freight packaging optimized for Colombo port customs clearance.
Complimentary 3D CAD & Structural Layouts
Prior to manufacturing, our structural engineering team delivers free 2D layout drafts and 3D volumetric warehouse simulations. We factor in your forklift turning radii, ceiling truss heights, column positions, and building code egress requirements at zero financial commitment.
Rigorous Batch QC & Certified Quality
Operating in compliance with CE Certificate No. 2435-CPR-8605159 and ISO 9001:2015, all components undergo yield stress testing, weld crack detection, and dry-film coating gauge verification. Mill test certificates (MTC) are supplied with all customs declarations.
Colombo Sea Route & Container Optimization
Shipping directly from modern Chinese manufacturing ports straight to Colombo Port (SAPT/CICT/JCT) within 14–18 days maritime transit. We engineer nested beam packing and bundled steel strapping designed to maximize container cubic utilization, lowering the freight cost per rack unit.
