Heavy Duty
Selective Pallet Racking Operations
Demonstration of beam deflection limits, upright column rigidity, and forklift aisle clearances under maximum rated load.
Engineering in Action
Pallet Racking Systems
Watch structural testing, automated rolling lines, and high-density operation across selective, drive-in, shuttle, and cantilever configurations built by Guangzhou Heda Shelves Co., Ltd.
Automation
Radio Shuttle Racking System
Semi-automated pallet carrier shuttle traveling through deep storage channels for cold-storage and fast-turnover warehouses.
High Density
Drive-In Racking System Stability
Inspection of heavy structural top tie-beams, reinforced floor anchors, and continuous pallet support rails.
Long Materials
Heavy Duty Cantilever Racking
Handling irregular and oversized loads including steel piping, structural timber, and metal coils with modular arm arms.
Dynamic Storage
Push Back Racking System
Multi-lane nested gravity cart mechanisms operating under standard ISO and South American standard wooden pallet loads.
Space Saving
VNA High-Bay Racking Layout
Floor guide rails, high-lift mast stability checks, and maximum volumetric storage for multi-SKU fulfillment centers.
FIFO Rotation
Gravity Flow Pallet Racking
Integrated brake rollers, speed controllers, and pallet separators delivering continuous rotation for food and pharma goods.
Manual Picking Solutions
Industrial Shelving Systems
Engineered boltless and longspan shelving systems designed for manual box picking, spare parts storage, and e-commerce sortation facilities.
Manual Picking
Medium & Longspan Shelving Assembly
Step-by-step modular assembly showing interlocking upright frames, drop-in step beams, and steel decking load integrity.
Archive & Parts
Track-Mounted Mobile Shelving
Mechanically driven carriage bases moving smoothly along tracks to double storage capacity without widening room footprints.
Vertical Floor Expansion
Mezzanine Floor Platforms
Structural steel mezzanines and rack-supported floor platforms engineered to turn clear ceiling height into usable picking, office, or assembly space.
Multi-Tier Floor
Rack-Supported Mezzanine Construction
Integrated pallet racking columns serving as heavy-duty structural posts for overhead picking walkways and integrated stairways.
Structural Steel
Heavy Duty Mezzanine Platform
Wide-span H-beam framework supporting uniform live loads from 300 kg/m² to over 1,000 kg/m² with modular safety handrails.
Access & Safety
Mezzanine Loading Gates & Flooring
Perforated anti-slip galvanized steel decking, safety kick plates, and pivoting pallet safety swing gates for cargo lifts.
