Engineered Product Catalog
High-Efficiency Manual Picking & Industrial Storage Racks
Explore our export-certified warehouse storage portfolios manufactured from certified high-tensile cold-rolled Q235B/Q355B steel, purpose-built for medium to heavy load configurations.
2001
Established Since
30,000m²
Production Facility
30,000t
Monthly Capacity
10,000+
Projects Deployed
Manufacturing Rigor
Integrated Engineering & Export Infrastructure
From initial structural FEA calculations to robotic continuous welding and dual electrostatic powder lines, we eliminate single-point operational vulnerabilities for global supply networks.
Stringent European Quality Accreditations
Every picking racking and pallet unit is audited against CE Certificate No. 2435-CPR-8605159 and ISO 9001:2015 standards. We supply traceable raw material mill test certificates (MTC) verifying precise tensile and yield capacities.
Complimentary 3D CAD & Seismic Design
Our in-house design engineers evaluate facility floor layout, clear headroom, material handling equipment (MHE) radius, and local seismic parameters (such as Chilean NCh 2369, Peruvian E.030, or US RMI) free of charge prior to cutting steel.
Full-Chain OEM / ODM Container Logistics
Direct packing operations optimize volumetric container stuffing into 40ft High Cube containers. Heavy uprights, step beams, and mesh panels are nested with industrial wrap to completely mitigate maritime transport abrasion.
Procurement Technical Whitepaper
Engineering Low-Latency Order Picking Architecture
In modern e-commerce fulfillment hubs, multi-tier logistics centers, and retail cold chains, direct access picking accounts for up to 55% of all warehouse operational costs. Selecting an engineered picking rack requires careful analysis of dynamic deflection, horizontal shear forces, and ergonomic picker reach. Standard light-duty steel shelving fails prematurely under repetitive picking vibration. Our wholesale manufacturing methodology integrates high-precision cold roll-formed upright frames featuring an Omega (Ω) profile with 50mm/75mm hole pitches, ensuring seamless beam height reconfigurability without structural buckling.
Surface treatment represents another major consideration for long-term operational resilience. Our automated 10-step surface finishing line begins with industrial-grade pickling and phosphating stages to strip hot-rolled scale, followed by electrostatic epoxy-polyester powder application cured at 180°C. This chemical-thermal bonding prevents corrosion and powder delamination, even in high-humidity coastal ports or refrigerated picking cold rooms operating down to -25°C.
| Racking System Type | Typical Load Rating | Access Strategy | MHE Compatibility | Ideal Industry Use-Case |
|---|---|---|---|---|
| Wide-Span Longspan Racking | 200 – 800 kg / level | 100% Immediate Hand Picking | Manual / Order Picker Carts | Automotive spare parts, apparel, hardware distribution |
| Multi-Tier Mezzanine Picking | 300 – 1,000 kg / m² | Multi-Level Vertical Batch Picking | Conveyor lines, spiral chutes, cargo lifts | High-SKU e-commerce fulfillment, 3PL cross-docks |
| Push-Back Heavy Picking Rack | 500 – 1,500 kg / pallet | High-Density LIFO Staging | Standard counterbalance, reach trucks | Buffer inventory, cold storage picking consolidation |
| Carton & Pallet Live Flow | 50 – 1,200 kg / lane | Automatic Gravity FIFO Separation | Tote bins, gravity rollers, automated picking | Pharmaceuticals, FMCG foods, cosmetics picking |
Structural reliability must be balanced against total landed cost (TLC). By importing directly from our Guangzhou production headquarters, wholesale distributors, general contractors, and EPC logistics integrators cut out intermediate trading markups while securing factory-direct component interchangeability for future warehouse expansions.
Global Market Dynamics
Emerging Technology & Procurement Sourcing Trends
Review the key technical, financial, and technological shifts that procurement directors must evaluate over the next five to ten years to prevent equipment obsolescence.
Automation Convergence
AMR & AGV-Hybrid Picking Integration
Traditional manual picking racks are transitioning into hybrid structures engineered to interface with Autonomous Mobile Robots (AMRs). Modern picking systems must incorporate floor rail tolerances, low-profile base plates, and unobstructed bottom levels to accommodate robotic navigation and auto-guided shelf-lifting bots.
Vertical Real Estate
High-Density Multi-Tier Picking Towers
With warehouse land costs rising worldwide, operations are maximizing vertical cubic volume. Industrial procurement increasingly prioritizes 3-to-5-level rack-supported mezzanines integrating vertical reciprocating conveyors (VRC) and high-density pick modules, multiplying effective square footage without expanding the building footprint.
Supply Chain Integrity
Certified High-Strength Low-Alloy Steels
Global logistics networks demand verified compliance with international structural codes like EN 15512 and RMI standards. Forward-looking buyers are shifting away from non-certified steel mills, requiring certified Q355B or cold-rolled micro-alloyed materials that lower overall steel deadweight while boosting dynamic load capacity and seismic resilience.
Procurement Clarifications
Frequently Asked Questions on Importing & Engineering
Key technical, freight, and quality inspection criteria addressed by our international project engineering team.
What structural parameters are required to generate an accurate 3D picking rack layout?
To provide an engineered proposal and CAD layout, our technical team requires: warehouse architectural floor drawings showing column placement and unobstructed height under sprinkler heads; floor slab concrete thickness, reinforcement schedule, and load limits (typically 2500–4000 PSI); exact carton or pallet dimensions (W x D x H) including product overhang; unit picking weight per level; SKU velocity profiles; and forklift or picking trolley models to establish aisle turning radius clearance.
How does Heda Shelves calculate and guarantee seismic safety for earthquake-prone regions?
Our engineers utilize structural analysis software to model dynamic seismic response spectra in accordance with international design standards. For high-seismic zones across South America, the Pacific Rim, and the Mediterranean, we re-engineer beam-to-column connector tabs, increase column material thickness, supply heavy-gauge floor base plates, and incorporate cross-aisle and longitudinal X-bracing. All engineering packages include calculation reports for review by your local registered structural engineer.
What surface treatment options protect racks in high-humidity or cold storage environments?
Standard picking systems feature an automated 10-step pickling, phosphating, and electrostatic powder coating process with dry film thickness maintained between 60 to 90 microns. For refrigerated cold stores, coastal shipping terminals, or facilities with high humidity, we provide pre-galvanized beam/panel options, hot-dip galvanizing per ASTM A123, or custom zinc-rich primer topcoats designed to prevent oxidation and peeling over decades of use.
What is the standard production lead time and international container stuffing process?
Supported by our monthly fabrication capacity of 30,000 tons, standard picking rack and wide-span shelving orders are produced within 2 to 4 weeks following final layout sign-off. Each shipment receives an engineered loading manifest: long uprights are secured on custom steel dunnage to avoid transit bending, crossbeams are strapped in heavy bundles, and decking panels are palletized. All containers are photographed during loading to confirm proper weight balance and cargo safety before export.
Can custom picking accessories, carton dividers, and safety mesh be incorporated?
Yes. We design and manufacture comprehensive picking ecosystem components, including full-depth corrugated carton dividers, anti-drop back wire mesh, perimeter collision upright protectors, magnetic location card rails, snap-in steel drop-in shelves, and heavy-duty corflute or polypropylene picking bins tailored directly to your inventory management system.
Accelerate Your Warehouse Picking Velocity Today
Connect directly with our senior application engineers to receive custom 3D structural drawings, bill of materials (BOM), and factory-direct pricing for your logistics and fulfillment projects.
